Plant Growth Monitoring System

1.Introduction to Plant Growth Monitoring System

Plant Growth Monitoring System refers to the real-time video monitoring (including daytime images and nighttime infrared images) of the growth and development status, pest and disease conditions, and disasters of crops by an automatic monitoring system. Combined with meteorological and soil moisture sensors and insect forecasting lights, it can automatically monitor the seedling conditions, insect conditions, and disasters in the field, allowing managers to remotely monitor the growth of crops and guide irrigation, fertilization, spraying, and other measures according to the needs of crops in different growth cycles.

2. Plant Growth Monitoring System System Composition

The system consists of a three-meter carbon steel bracket, HK2 Hikvision camera, solar power supply system (including protective box), and cloud platform.

3. Plant Growth Monitoring System Technical Parameters

1. Supports intelligent detection such as regional intrusion detection, cross-border detection, entry detection and exit detection

2. Adopt high-efficiency fill light array, low power consumption, infrared fill light 100 m

3. Built-in heated glass, effective defogging

4.Support ultra-low illumination, 0.005 Lux F1.6 (color), 0.001 Lux F1.6 (black and white), 0 Lux wi th IR

5. Support 23x optical zoom and 16x digital zoom

6. Support three-stream technology, each stream can independently configure resolution and frame rate

7.Support 3D digital noise reduction and 120 dB wide dynamic range

8.Support scheduled capture and event capture functions

9.Supports scheduled tasks, one-key watch, and one-key cruise functions

10.Support Hikvision SDK, open network video interface, ISAPI, GB/T28181, ISUP, EZVIZ

11. Supports up to 256 GB MicroSD card storage

12. Strong anti-interference ability, suitable for harsh electromagnetic environment, in line with GB/T17626.2/3/4/5/6 level 4 standards, IP66

4. Plant Growth Monitoring System Cloud Platform

1.CS architecture software platform, supports direct observation via mobile phone and PC browser, no need to install additional software.

2.Support multiple accounts and multiple devices to log in

3.Support real-time data display and historical data display dashboard

4. Cloud servers and cloud data storage are stable and reliable, easy to expand, and load balanced.

5.Support SMS alarm and threshold setting

6.Support map display and view device information.

7.Support data curve analysis

8.Support data export in table format

9.Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.

10. Support data post-processing function

11.Support external running of javascript scripts
