Weather Station Monitoring System

1.Weather Station Monitoring System Product Introduction

Weather Station Monitoring System is a high-precision meteorological observation device that is highly integrated, low-power, can be quickly installed, and is easy to use for field monitoring.

The equipment consists of five parts: meteorological sensor, collector, solar power supply system, pole bracket and cloud platform.It is debugging-free and can be quickly deployed.It is widely used in meteorology, agriculture, forestry, environmental protection, ocean, airport, port, scientific investigation, campus education and other fields.

2.Weather Station Monitoring System Product Features

1.Low power collector: static power consumption is less than 50uA

2.Standard GPRS networking, support for extended Bluetooth and wired transmission

3.7-inch Android touch screen, version: 4.4.2, quad-core Cortex™-A7, 512M/4G (optional)

4.Support modbus485 sensor expansion

5.Solar charging management MPPT automatic power point tracking

6.Three-meter carbon steel bracket, two sections of flange butt joint

7.SMS alarm: send SMS to the designated mobile phone after exceeding the limit

8.ABS material protective box, corrosion-resistant, anti-oxidation, waterproof grade IP66

3.Weather Station Monitoring System Technical Parameters

1) Collector power supply interface: GX-12-3P plug, input voltage 5V, with RS232 output Json data format, collector power supply: DC5V±0.5V peak current 1A,

2) Sensor modbus, 485 interface: GX-12-4P plug, output power supply voltage 12V/1A, device configuration interface: GX-12-4P plug, input voltage 5V

3) Solar power supply, lead-acid battery configuration, optional 30W 20AH/50W 40AH/100W 100AH.Charge controller: 150W, MPPT automatic power point tracking, efficiency increased by 20%

4) Data upload interval: 1 minute - 1000 minutes adjustable

5) 7-inch Android touch screen, screen size: 1024*600 RGB LCD (optional)

6) Some sensor parameters

7) The whole machine has obtained the calibration certificate of the National Meteorological Metrology Station

8) The manufacturing enterprise has ISO quality management system, environmental management system and occupational health management system certification

9) The manufacturer has a computer software registration certificate

10) The manufacturer is a 3A credit enterprise

4.Weather Station Monitoring System Product Dimensions

5.Weather Station Monitoring System Product Structure Diagram

6.Weather Station Monitoring System Host Computer Software Introduction

1.PC stand-alone version of data receiving, storage, viewing and analysis software

2.Support serial port data reception, processing and display

3.Support json string, modbus485 and other communication methods

4.The storage time can be set by yourself, and the acquisition time can be set by yourself in modbus485 acquisition mode

5.Support self-service addition, deletion, and modification of monitoring parameter protocols, names, icons, etc.

6.Support data post-processing function

7.Support external running of javascript scripts

7.Weather Station Monitoring System Android APP Introduction

1.Android stand-alone data receiving, storage, viewing and analysis software

2.Support Bluetooth data reception

3.The software receives and processes the data in the background after the phone goes into sleep mode

4.Automatically add devices with json data, and modbus devices support adding devices by scanning codes

5.Support historical data viewing, analysis, and table export, support curve display, and single data point viewing.

6.Support data post-processing function

7.Support external running of javascript scripts

8.Weather Station Monitoring System Cloud Platform Introduction

1.CS architecture software platform, supports direct observation through mobile phones and PC browsers, without the need to install additional software.

2.Support multiple accounts and multiple devices to log in

3.Support real-time data display and historical data display dashboard

4.Cloud servers and cloud data storage are stable, reliable, easy to expand, and load balanced.

5.Support SMS alarm and threshold setting

6.Support map display and view device information.

7.Support data curve analysis

8.Support data export in table format

9.Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.

10.Support data post-processing function

11.Support external running of javascript scripts
